Remote control Support browser remote, compatible with devices on different platforms
8 customisable XLR outputs
S/PDIF digital inputs/outputs and AES/EBU output
16 bus and 4 mono output bus, 5 stereo output
1 stereo monitor bus
1 stereo track monitor output and 1 earphone output interface
7″ IPS 1024x600mm touch screen
8 built in FX modules – 2 reverbs, 2 modulation, 2 delays, 2 15-band GEQ
IPS multi-function touch screen angle is fully adjustable to user’s preference
9x100mm ALPS motorized faders
High quality Neutrik connectors
2 USB interfaces support flash disk and recording, support WAV format output
Latency: < 1.2ms
Dimensions:
DX20 digital mixer is a fully functional compact digital mixer that Soundking enters the digital mixer market. It integrates the new concept of modern digital mixer and traditional mixer operation.Its compact body, simple operation interface, professional sound mixing effect, expansion card: support B-type 16×16 USB audio interface or 16×16 network transmission LAN network interface, which can not only play an outstanding ability in a professional performance, but also fully satisfy the inexperienced individual users to provide powerful effects.DX20 combines the advantages of high-end hardware/touch sliding control and IPad tablet remote control operation.
It adopts the fourth-generation 40-bit SHARC floating-point processor, 24bit/48kHz analog-to-digital/digital-to-analog conversion, built-in 8 effectors, with reverb, delay, modulation and GEQ. (20 input channels) 12 input professional microphones and 2 input stereo and professional digital signal input ports. The 16 input bus contains 8 custom analog output and digital output ports.
Provide users with multiple configuration options for basic version/multi-track recording version/network transmission version. At the same time, DX20 is equipped with two USB ports for playing, recording, scene storage and ipad remote access. DX20 is equipped with a 7-inch Android driven HD touch screen, WIFI wireless control, with 9 100mm electric faders to adjust parameters, intuitive control.
