OC818 Live Set Austrian Audio

תיאור

מאפיינים עיקריים
Handmade CKR12 ceramic capsule
Made to the same critical dimensions as the classic CK12 capsules
Multiple polar patterns
Cardioid, omnidirectional & custom programmable
Microprocessor control of polarisation voltages
Allows remote controlled polar pattern settings
Two different analogue high-pass filters with three settings
40 Hz, 80 Hz, 160 Hz
Two different types of analogue pads
-10 dB, -20 dB
Dual outputs
for recording each diaphragm separately
מפרט טכניDirectional characteristics:MultiImpedance:275 Ω (symmetrical)Polar pattern:cardioid, omnidirectional, figure-8, supercardioid & custom programmableLoad impedance:> 1 kΩFrequency range:20 Hz – 20 kHzSupply voltage:48 V (< 4mA, typical 2.1mA)Sensitivity (all directions):13mV/PaMain Connector:XLR 3 pinEquivalent noise level:9 dB SPL (A)or remote:Mini XLR 5 pin Connector for back membraneMax SPL:148 dB SPL (158 dB SPL)Dimensions:157 x 63 x 35 mmSwitchable pad:-10 dB, -20 dBWeight:360gAnalog Low Cut filter:40 Hz (2nd order), 80 Hz (2nd order), 160 Hz (1st order down to 80Hz, 2nd order below)
