WA-412 Warm Audio

תיאור

מאפיינים עיקריים
• 4 CHANNEL MICROPHONE PREAMPLIFIER + INSTRUMENT DI
• FULLY DISCRETE, TRANSFORMER COUPLED, THROUGH-HOLE COMPONENT TOPOLOGY
• ALTRAN USA CUSTOM WOUND, PREMIUM INPUT AND OUTPUT TRANSFORMERS
• X520 DISCRETE OP-AMP IN EVERY CHANNEL, SOCKETED FOR CONVENIENCE. CAN BE USER-REPLACED WITH • MOST 6 PIN, DISCRETE OP-AMPS FOR VARYING FLAVOR & TONE
• 65DB OF GAIN
• +48 VOLT PHANTOM POWER
• LED METERING
• OUTPUT TRIM KNOB FOR PRECISE LEVEL CONTROL AND TONE SCULPTING
• INTERNAL POWER SUPPLY (GROUNDED, 3 PIN IEC CORD)
מפרט טכניINPUTSMICROPHONE XLR & ACTIVE INSTRUMENT 2MEG OHM HI-ZOUTPUTSTRANSFORMER BALANCED XLR & TRS-20DB PADPADS BOTH MIC AND INSTRUMENT DI INPUTSTONE BUTTON INPUT IMPEDANCESWITCHES FROM 600 OHMS TO 150 OHMS (AFFECTS THE TONE OF BOTH THE MIC AND HI-Z INPUTS)SELF NOISE<-90DB (NOMINAL)FREQUENCY RESPONSE20HZ TO 20KHZ <+/-0.25DB (TONE BUTTON OUT), 20HZ TO 20KHZ +/-2DB (TONE BUTTON IN)
