FRFR-108 HeadRush

תיאור

מאפיינים עיקריים
FRFR-108 Features:
• Specially-voiced 8-inch woofer and high-frequency compression driver
• 2000 watts of peak power
• (2) XLR/TRS 1/4-inch combo inputs
• Independent volume controls and clip indicator per input
• Contour EQ switch
• Ground-Lift switch
• XLR output for FOH or additional FRFR-108 cabs
• Lightweight (19lbs) and flexible tilt-back cabinet design
• Cabinet can be pole-mounted
Output Power_2000 W (peak, 1300 LF + 700 HF)_1000 W (continuous RMS, 650 LF + 350 HF)DriversLow-Frequency8.0” (203 mm) driver, 2.5” (65 mm) high-temperature voice coilHigh-Frequency1.4” (35 mm) neodymium driver with precision waveguideCrossover Frequency_2.5 KHzMaximum SPL_129 dB (peak), 126 dB (continuous) (dB-SPL @ 1 m)Frequency Response_62 Hz – 20 kHz (+3 dB)Frequency Range_2 Hz – 22 kHz (-10 dB)Horn Coverage_90º horizontal x 60º vertical (nominal)Equalization_Contour switch with low- and high-frequency +3 dB boostConnectors_(2) XLR/TRS 1/4” (6.35 mm) combo inputs_(1) XLR link output_(1) IEC power cable inputControls_Power switch, (2) volume control knobs (1 per input), EQ contour switch, ground-lift switchIndicators_Power LED (rear panel), clip limiter LEDProtection_Electronic clip, thermal & transducer overdrivePowerConnectionIECInput Voltage100 V~, 110–120 V~, 220–240 V~; 50/60 Hz (switchable)Fuse100–120V T10AL AC250V_220–240V T5AL AC250VConsumption800 WEnclosure_Trapezoidal, injection-molded polypropylene enclosure with perforated steel grilleMounting_Standard 36 mm pole socketDimensions_17.1” x 10.1” x 9.6”(height x width x depth)434 x 256 x 245 mmWeight_9.2 kg_20.2 Ib.כללימק”ט52-FRFR108
